TLEC-5 / 3.2 ALKALINE ELECTROLYZER
Efficiency Redefined
Electrolyzer Specifications
The electrolyzer in this equipment utilizes a positive and negative series connection mode. With an electricity rating of 4000 A/m³, the unit’s DC energy consumption is less than 4.3 kWh/Nm³H2. It boasts a rated hydrogen production capacity of 5 Nm³/h, a rated pressure of 3.2 MPa, and a rated operating temperature of 85 ± 5°C.
Purity Levels
The crude hydrogen purity exceeds 99.8%, while crude oxygen purity is above 99.2%.
Versatile Applications
Designed to cater to diverse applications such as power plants, semiconductor facilities, universities, and research institutes, this hydrogen production system offers exceptional technical advantages.
Advanced Control Technology
Featuring advanced digital control technology, the system allows for adjustable parameters including temperature, voltage, current, and time.
Operational Modes
The system operates under constant voltage, constant current, and constant power control modes, with the option for automatic or manual control.
Security and Maintenance
Equipped with 24-hour unattended security features, the system is easily maintainable, ensuring reliable and efficient operation.
